Description:
Spark Solar Solutions introduces the best 5kW grid connected solar system for homes. A 5 kW solar system generates 30 units every day from morning 8 am to 6 pm which is sufficient to run multiple air conditioners along with Refrigerator, Television, Fans, and lights during the day in a big house.
Product Overview
|
Solar Panel |
SHARK 445 bifacial (445 watt Mono-PERC Solar Panel) |
|
Space required |
280-300 sq. ft. |
|
1 Panel dimension |
Length – 6.9 ft, width – 3.9 ft |
|
1-panel weight |
28 kg |
|
Solar Inverter |
FUSION 53 |
This system is best suited for reducing your electricity bill. It will help you to cut-down your monthly bill from 60 to 100% depending upon the generation & usability.
Send generated power back to the grid during the day & ustilize the same after returning home at evening. It is best suited for homes getting Rs.9000/- or above electricity bill monthly.
Eligibility - For 5kW or above sanctioned grid connections only
Package Components:
|
Solar Panel |
Loom Solar Panel SHARK 445 Bi-Facial |
|
Solar Inverter |
5kw Three Phase On-grid Inverter, FUSION 53 |
|
Structure |
Not Included |
|
Connector Type |
MC4 connector 1in 1 out |
|
Connecting wires |
Solar DC Wire 4sqmm-15mtr. Pair / AC Wire 4sqmm 2core |
|
Protection & Safety Devices |
DCDB 1IN 1OUT / ACDB Single Phase / Lightning Arrester(LA) / 1 mtr. Copper Earthing electrode with Chemical Bag / Single Core AC wire for Earthing |
